Agent Governance & Trust Framework

3. Key Components

3.1 Manifest System

Agent identity documents define trust level, data classification, permitted tools, and delegation rules. Manifests are YAML files stored in state/manifests/ with cryptographic signing for tamper evidence.

agent_id: security-analyst
manifest_id: gov-sec-analyst-v2
manifest_version: "2.1.0"
trust_level: 4                    # 1-5 scale
data_classification: confidential  # public | internal | confidential | restricted
permitted_tools:
  - "Read"
  - "Grep"
  - "Bash"
  - "mcp__*"                      # fnmatch wildcards supported
permitted_delegations:
  - "pentest-agent"
  - "compliance-*"
human_required: false
max_autonomy_depth: 3             # Delegation depth budget
max_delegation_count: 5           # Breadth limit per session
model_id: claude-opus-4-6
model_version: "4.6"

Manifest Resolution Logic

Static + Parent: Load static manifest and enforce parent ceiling (intersect capabilities)
Static Only: Root agent, use static manifest as authoritative
Parent Only: No static manifest found, derive restrictive child from parent
Neither: Default to trust_level=1, data_classification=public, no tools, no delegation

Parent ceiling enforcement is the security foundation: a child can never exceed its parent's trust level, data classification, or autonomy depth. This creates a monotonically decreasing privilege chain.

Field	Type	Ceiling Rule
`trust_level`	Integer (1-5)	min(static, parent)
`data_classification`	Enum	Lower classification wins
`max_autonomy_depth`	Integer	min(static, parent - 1)
`permitted_tools`	List[pattern]	Union (additive)
`permitted_delegations`	List[pattern]	Union (additive)

Cryptographic Signing

Manifests are signed with HMAC-SHA256 on load. The signing key is a 32-byte secret stored in state/.signing-key with 0600 permissions. Signature verification happens during manifest validation — tampered manifests fail validation and fall back to default-restrictive.

# Canonical manifest for signing (excludes volatile fields)
canonical = json.dumps(
    {k: v for k, v in manifest.items()
     if k not in {"manifest_signature", "manifest_hash",
                  "audit_session_id", "audit_parent_id"}},
    sort_keys=True, separators=(",", ":"))

signature = hmac.new(signing_key, canonical.encode(), hashlib.sha256).hexdigest()

3.2 Trust Broker

Mediates inter-agent delegation by validating breadth/depth limits, classification boundaries, and permitted targets. Issues delegation tokens for forensic linkage and registers resolved child manifests in a session-scoped registry.

Delegation Validation Rules

Breadth Limit

Query audit bus for previous DELEGATION_EVENT events from this agent in this session. If count >= max_delegation_count, deny with TRUST_DENY event. Prevents agent from spawning unlimited child tasks.

Depth Budget

Check parent's max_autonomy_depth. If <= 0, escalate to human gate with TRUST_DENY. Child receives parent.depth - 1, creating a monotonically decreasing budget.

Classification Ceiling

Child's data_classification cannot exceed parent's. If target manifest requests higher classification, deny delegation. Prevents data exfiltration via upward delegation.

Trust Escalation

Child's trust_level cannot exceed parent's. Defense-in-depth check — should be caught by ceiling enforcement, but trust broker validates independently.

Permitted Targets

Target agent ID must match a pattern in parent's permitted_delegations list (supports fnmatch wildcards). Prevents delegation to arbitrary agents.

Delegation Token

SHA-256 hash of session_id:parent_manifest_id:child_manifest_id:timestamp:nonce. Stored in DELEGATION_EVENT detail for forensic chain reconstruction.

Manifest Registry

A JSON file (state/manifest-registry.json) with file-lock-based concurrency control. Stores active child manifests keyed by session_id:agent_id. TTL purging (1 hour) removes stale entries. SessionStart hook purges on startup.

3.3 Policy Engine

Classifies tools into risk tiers (exempt/standard/elevated) and enforces manifest permissions + conductor tier matrix to decide allow/deny/human_gate. Unknown tools default to elevated (fail toward scrutiny).

Tool Risk Tiers

Tier	Examples	Audit Strategy	Gate Logic
exempt	Read, Glob, Grep, TaskList	Async emit (nowait queue)	Always allow, skip policy checks
standard	Edit, Write, Task, Bash	Sync audit if tier >= STANDARD	Check manifest permissions, depth, human_required
elevated	memory_store, NotebookEdit, MCP tools	Always sync audit	Check + tier matrix (MAJOR + elevated = human_gate)

Conductor Tier Matrix

Conductor plugin exports current task tier (TRIVIAL/MINOR/STANDARD/MAJOR) in conductor-state.json. Policy engine loads this and applies tier-specific gates:

# MAJOR tier + elevated tool = always human gate
if tool_tier == "elevated" and conductor_tier == "MAJOR":
    return PolicyDecision("human_gate",
                         "MAJOR task + elevated tool requires human approval")

# Synchronous audit for elevated or STANDARD+
if tool_tier == "elevated" or conductor_tier in ("STANDARD", "MAJOR"):
    audit_bus.emit(EventType.POLICY_CHECK, manifest, tool_name=tool_name)
else:
    audit_bus.emit_nowait(EventType.TOOL_INVOKED, manifest, tool_name=tool_name)

3.4 Audit Bus

SQLite database with WAL mode for concurrent writes. Bounded async queue (256 depth) for low-risk events, synchronous writes for critical events, JSON buffer fallback for database failures. Supports JSONL export and retention-based archival.

Event Types (15 Total)

Operational

TOOL_INVOKED
MEMORY_WRITE
MEMORY_READ
MANIFEST_LOADED
MANIFEST_DERIVED

Governance

POLICY_CHECK
POLICY_DENY
TRUST_CHECK
TRUST_DENY
DELEGATION_EVENT

Security

HUMAN_GATE
CIRCUIT_BREAK
LLM_THREAT
CONTEXT_PRESSURE
BUFFER_REPLAY

Schema & Indexes

CREATE TABLE audit_events (
    id INTEGER PRIMARY KEY AUTOINCREMENT,
    event_id TEXT UNIQUE NOT NULL,
    timestamp TEXT NOT NULL,
    audit_session_id TEXT NOT NULL,
    event_type TEXT NOT NULL,
    agent_id TEXT NOT NULL,
    manifest_id TEXT,
    manifest_version TEXT,
    manifest_hash TEXT,
    trust_level INTEGER,
    data_classification TEXT,
    autonomy_depth_remaining INTEGER,
    tool_name TEXT,
    task_id TEXT,
    target_agent_id TEXT,
    context_hash TEXT,
    detail TEXT,               -- JSON-encoded event-specific fields
    outcome TEXT               -- allow | deny | escalate | warn
);

CREATE INDEX idx_audit_session ON audit_events(audit_session_id);
CREATE INDEX idx_audit_timestamp ON audit_events(timestamp);
CREATE INDEX idx_audit_agent ON audit_events(agent_id);
CREATE INDEX idx_audit_type ON audit_events(event_type);

Buffered Fallback

When SQLite writes fail (locked, disk full, corrupted), events are appended to state/audit-buffer.jsonl. On next startup, buffer is renamed to .replaying, events are replayed to database, then buffer is deleted. This ensures zero event loss even during database failures.

3.5 Memory Governor

Intercepts memory writes via PreToolUse hook on mcp__claude-memory__memory_store. Classifies content using regex patterns, enforces agent classification ceiling, blocks restricted data, queues confidential writes for review, adds 9-field provenance tags.

Classification Patterns

restricted:
  - '\b(password|secret|api[_-]?key|private[_-]?key|token|credential)\s*[:=]\s*\S+'
  - '\b\d{3}-\d{2}-\d{4}\b'                    # SSN pattern
  - '-----BEGIN\s+(RSA|EC|PRIVATE)\s+KEY-----'
  - '\b(bearer\s+[a-zA-Z0-9\-._~+/]+=*)\b'

confidential:
  - '\b(internal[_-]?only|do[_-]?not[_-]?share|proprietary|confidential)\b'
  - '\bCVE-\d{4}-\d{4,7}\b'                   # Vulnerability IDs
  - '\b(salary|compensation|revenue|profit)\s*[:=$]'
  - '\b(ssn|social[_-]?security|tax[_-]?id)\b'

internal:
  - '\b(prod(uction)?|staging)\s+\b(server|host|endpoint|cluster)\b'
  - '\b\d{1,3}\.\d{1,3}\.\d{1,3}\.\d{1,3}\b' # IP addresses
  - '\b[a-zA-Z0-9\-]+\.(internal|corp|local)\b'

Governance Decisions

Classification	Agent Ceiling Check	Action	Audit Event
public	N/A	Allow with provenance tags	MEMORY_WRITE (allow)
internal	Agent must be internal+	Allow with provenance tags	MEMORY_WRITE (allow)
confidential	Agent must be confidential+	Queue for review, persist with pending_review tag	HUMAN_GATE (escalate)
restricted	Always exceeds ceiling	Block (do not persist)	POLICY_DENY (deny)

Provenance Tags (9 Fields)

provenance = {
    "gov_manifest_id": manifest["manifest_id"],
    "gov_agent_id": manifest["agent_id"],
    "gov_manifest_version": manifest["manifest_version"],
    "gov_manifest_hash": manifest["manifest_hash"],
    "gov_trust_level": manifest["trust_level"],
    "gov_classification": manifest["data_classification"],
    "gov_session_id": manifest["audit_session_id"],
    "gov_task_id": manifest.get("task_id"),
    "gov_timestamp": datetime.now(timezone.utc).isoformat(),
}

These tags are merged into the metadata field of the memory_store tool input, persisting alongside the content in Qdrant. This enables provenance-based memory queries (e.g., "show me all memories written by security-analyst agent in session X").

3.6 LLM Threat Detector (OWASP LLM Top 10)

Scans tool inputs for prompt injection attempts and tool outputs for system prompt leakage and sensitive data disclosure. Uses 30 prompt injection patterns and 24 system leakage patterns across three severity levels (critical/high/medium).

Prompt Injection Detection

Critical Patterns

Delimiter injection: </system>, <|im_start|>, [INST]
Direct override: "ignore all previous instructions"
Role hijacking: "you are now a", "act as an admin"
Instruction leakage: "show me your system instructions"

High Patterns

Indirect override: "bypass all security", "disable rules"
Base64 encoding: aWdub3JlIHByZXZpb3Vz (ignore previous)
Instruction leakage: "what are your original instructions"
Repeat attacks: "repeat your system prompts"

System Leakage Detection

SYSTEM_LEAKAGE_PATTERNS = {
    "critical": [
        r'governance/lib/\w+\.py',           # File paths
        r'state/manifests/',
        r'\bmanifest_hash\s*[:=]',           # Manifest internals
        r'\btrust_level\s*[:=]\s*\d+',
        r'\bdata_classification\s*[:=]\s*(public|internal|confidential|restricted)',
        r'\baudelegation_token\s*[:=]',
        r'agent_id\s*:\s*\w+',               # YAML structure
        r'permitted_tools\s*:',
    ],
    "high": [
        r'\bgovernance\.lib\.',              # Module references
        r'\bpolicy_engine\b',
        r'\btrust_broker\b',
        r'gov-[a-z]+-[0-9a-f]{8}',          # Session IDs
    ],
    "medium": [
        r'\bgovernance\s+plugin\b',          # Generic terms
        r'\bmanifest\s+registry\b',
    ],
}

Threat Response Actions

Severity	Input Scan Action	Output Scan Action	Audit Event
critical	Block tool execution	Block output, emit alert	LLM_THREAT (block)
high	Block tool execution	Block output, emit alert	LLM_THREAT (block)
medium	Log warning, allow	Log warning, allow	LLM_THREAT (warn)

3.7 SIEM Integration & Alerting

Sends governance security events to external monitoring systems via webhook (n8n compatible) and syslog (Wazuh compatible). Alerting is fail-open — failures never block governance operations.

Alert Triggers

Five event types trigger alerts: policy_deny, trust_deny, circuit_break, human_gate, llm_threat. All other events are audit-only.

Webhook Payload (n8n)

{
  "source": "governance",
  "timestamp": "2026-03-17T14:23:45.123456Z",
  "event_type": "llm_threat",
  "agent_id": "security-analyst",
  "tool_name": "Bash",
  "outcome": "block",
  "detail": {
    "threat_type": "prompt_injection",
    "severity": "critical",
    "pattern_matched": "\\bignore\\s+all\\s+previous\\s+instructions\\b",
    "scan_type": "input",
    "detail": "Detected prompt injection pattern in content"
  },
  "session_id": "gov-sess-a4f8d2c1",
  "manifest_id": "gov-sec-analyst-v2",
  "trust_level": 4
}

Syslog Format (RFC 5424)

<131>1 2026-03-17T14:23:45.123456Z governance claude-code - - - \
event_type=llm_threat agent_id=security-analyst tool_name=Bash \
outcome=block session_id=gov-sess-a4f8d2c1

PRI calculation: facility * 8 + severity. Facility defaults to local0 (16). Severity is 3 (error) for deny/block, 4 (warning) for escalate/warn. Wazuh can parse these via custom decoder rules.

3.8 Metrics Collection

Separate SQLite database (state/governance-metrics.db) tracks operational metrics: agent success/failure rates, gate trigger frequency, confidence scores, delegation depth, circuit breaker activations. Enables drift detection and performance monitoring.

CREATE TABLE governance_metrics (
    id INTEGER PRIMARY KEY AUTOINCREMENT,
    timestamp TEXT NOT NULL,
    session_id TEXT NOT NULL,
    metric_type TEXT NOT NULL,     -- agent_success | gate_trigger | delegation_depth
    agent_id TEXT,
    value REAL NOT NULL,
    metadata TEXT                   -- JSON for additional context
);

Example Metrics

agent_success: value=1.0 for successful tool execution, 0.0 for failure
gate_trigger: value=1.0 each time a human_gate is triggered
delegation_depth: value=N for delegation at depth N
circuit_break: value=1.0 each time autonomy depth exhausted
confidence_score: value=0.0-1.0 from conductor confidence signal

3.9 Environment-Aware Policy

Detects environment from hostname or GOVERNANCE_ENV env var, loads base policy from governance-policy.yaml, then applies environment-specific overrides from state/env-overrides/<env>.yaml. Enables different retention policies, gate enforcement modes, and alerting configs per environment.

# state/env-overrides/production.yaml
retention:
  audit_events:
    retention_days: 365      # Override from base 90 days
  metrics:
    retention_days: 730

alerting:
  enabled: true
  webhook:
    enabled: true
    url: "https://n8n.example.com/webhook/governance"
  syslog:
    enabled: true
    host: "siem.example.com"
    port: 514

Centralized Policy (Single Source of Truth)
All governance components reference state/governance-policy.yaml. No scattered config files. Tool tiers, classification patterns, gate rules, tier matrix, and retention policies all in one place.

4. Requirements

4.1 Manifest Identity

REQ-GOV-001: Manifest Fields

Every agent manifest MUST include: agent_id, manifest_id, manifest_version, trust_level (1-5), data_classification (public/internal/confidential/restricted), permitted_tools (list of fnmatch patterns), permitted_delegations (list), human_required (bool), max_autonomy_depth (int), max_delegation_count (int).

REQ-GOV-002: Cryptographic Signing

Manifests MUST be signed with HMAC-SHA256 using a 32-byte signing key stored in state/.signing-key. Signatures MUST be verified on manifest load. Tampered manifests MUST fail validation and fall back to default-restrictive manifest.

REQ-GOV-003: Manifest Hash

Every manifest MUST include a SHA-256 hash of canonicalized JSON content (excluding manifest_signature and manifest_hash fields). Hash MUST be recomputed on each load to detect tampering.

REQ-GOV-004: Parent Ceiling Enforcement

When resolving a child manifest with parent context, the system MUST enforce: trust_level = min(static, parent), data_classification = lower(static, parent), max_autonomy_depth = min(static, parent - 1). Child capabilities MUST be monotonically decreasing along delegation chains.

REQ-GOV-005: Model Inventory

Manifests MUST track model_id and model_version fields. SessionStart hook MUST populate these from runtime context. Audit events MUST include manifest_version for model drift analysis.

4.2 Trust Broker

REQ-GOV-006: Breadth Limit

Trust broker MUST query audit bus for DELEGATION_EVENT count from source agent in current session. If count >= max_delegation_count, MUST deny with TRUST_DENY event and reason "delegation_count_exceeded".

REQ-GOV-007: Depth Budget

Trust broker MUST check parent max_autonomy_depth. If <= 0, MUST escalate to human_gate with TRUST_DENY event. Child MUST receive parent.depth - 1 in resolved manifest.

REQ-GOV-008: Classification Boundary

Trust broker MUST deny delegation if target data_classification exceeds parent data_classification (using CLASSIFICATION_ORDER = ["public", "internal", "confidential", "restricted"]). MUST emit TRUST_DENY with reason "classification_boundary_violation".

REQ-GOV-009: Trust Escalation

Trust broker MUST deny delegation if target trust_level exceeds parent trust_level. MUST emit TRUST_DENY with reason "trust_escalation_attempt".

REQ-GOV-010: Permitted Delegations

Trust broker MUST check if target agent_id matches any pattern in parent's permitted_delegations list (using fnmatch). If no match, MUST deny with TRUST_DENY and reason "delegation_target_not_permitted".

REQ-GOV-011: Delegation Token

Trust broker MUST issue a unique delegation token for each approved delegation, computed as SHA-256(session_id:parent_manifest_id:target_manifest_id:timestamp:nonce)[:24]. Token MUST be stored in DELEGATION_EVENT detail field.

REQ-GOV-012: Manifest Registry

Trust broker MUST maintain a session-scoped registry of active child manifests at state/manifest-registry.json. Registry operations MUST use file locking (fcntl.flock) for concurrency safety. TTL purging (1 hour) MUST remove stale entries.

4.3 Policy Engine

REQ-GOV-013: Tool Classification

Policy engine MUST classify tools into exempt/standard/elevated tiers using state/tool-tiers.yaml. Unknown tools MUST default to "elevated" tier (fail toward scrutiny).

REQ-GOV-014: Exempt Tools

Exempt tools (Read, Glob, Grep, TaskList, TaskGet) MUST always be allowed with async audit emission (nowait queue). Policy checks MUST be skipped for exempt tools.

REQ-GOV-015: Permitted Tools Check

For standard and elevated tools, policy engine MUST verify tool_name matches a pattern in manifest.permitted_tools (using fnmatch). If no match, MUST deny with POLICY_DENY and reason "tool_not_permitted".

REQ-GOV-016: Autonomy Depth Gate

Policy engine MUST check manifest.max_autonomy_depth. If <= 0, MUST emit CIRCUIT_BREAK and return human_gate decision with reason "autonomy_depth_exhausted".

REQ-GOV-017: Manifest Human Gate

Policy engine MUST check manifest.human_required. If true, MUST emit HUMAN_GATE and return human_gate decision with reason "agent manifest requires human approval".

REQ-GOV-018: Conductor Tier Matrix

Policy engine MUST load conductor_tier from conductor-state.json. If tier is "MAJOR" and tool tier is "elevated", MUST emit HUMAN_GATE and return human_gate decision with reason "MAJOR task + elevated tool requires human approval".

REQ-GOV-019: Sync Audit Strategy

Policy engine MUST emit synchronous POLICY_CHECK events for elevated tools or when conductor_tier is STANDARD or MAJOR. All other allowed tools MUST use async emit_nowait.

4.4 Audit Bus

REQ-GOV-020: SQLite WAL Mode

Audit bus MUST use SQLite with WAL (Write-Ahead Logging) mode and NORMAL synchronous mode for concurrent write safety and performance. Database MUST be at state/audit.db.

REQ-GOV-021: Event Types

Audit bus MUST support 15 event types: TOOL_INVOKED, DELEGATION_EVENT, CONTEXT_PRESSURE, MEMORY_WRITE, MEMORY_READ, POLICY_CHECK, POLICY_DENY, HUMAN_GATE, MANIFEST_LOADED, MANIFEST_DERIVED, TRUST_CHECK, TRUST_DENY, CIRCUIT_BREAK, BUFFER_REPLAY, LLM_THREAT.

REQ-GOV-022: Bounded Queue

Audit bus MUST implement a bounded queue (256 depth) with single daemon worker thread for async event emission. If queue is full, MUST fall back to synchronous emit.

REQ-GOV-023: Buffer Fallback

When SQLite writes fail, audit bus MUST append events to state/audit-buffer.jsonl. On next SessionStart, MUST replay buffered events to database and delete buffer file.

REQ-GOV-024: Event Schema

Every audit event MUST include: event_id (UUID), timestamp (ISO 8601), audit_session_id, event_type, agent_id, manifest_id, manifest_version, manifest_hash, trust_level, data_classification, autonomy_depth_remaining, tool_name, task_id, target_agent_id, context_hash, detail (JSON), outcome (allow/deny/escalate/warn).

REQ-GOV-025: Retention & Archival

Audit bus MUST support retention-based purging with configurable retention_days (default 90). Old events MUST be archived to JSONL before deletion. Archive path defaults to state/archive/audit-archive-YYYYMMDD.jsonl.

4.5 Memory Governor

REQ-GOV-026: Content Classification

Memory governor MUST classify content using regex patterns from state/classification-patterns.yaml. MUST scan restricted patterns first, then confidential, then internal. Highest match wins. Unmatched content defaults to "public".

REQ-GOV-027: Classification Ceiling

Memory governor MUST deny writes if content classification exceeds agent data_classification ceiling (using CLASSIFICATION_ORDER). MUST emit POLICY_DENY with reason "classification_ceiling_exceeded".

REQ-GOV-028: Restricted Block

Memory governor MUST block (not persist) all restricted content with POLICY_DENY event and reason "restricted_content_blocked". Human approval via /governance-review required before storage.

REQ-GOV-029: Confidential Queue

Memory governor MUST allow confidential writes to proceed but tag with gov_approval_status="pending_review". MUST emit HUMAN_GATE event with reason "confidential_write_queued".

REQ-GOV-030: Provenance Tags

Memory governor MUST add 9 provenance fields to all memory writes: gov_manifest_id, gov_agent_id, gov_manifest_version, gov_manifest_hash, gov_trust_level, gov_classification, gov_session_id, gov_task_id, gov_timestamp.

4.6 LLM Threat Detection

REQ-GOV-031: Input Scanning

LLM threat detector MUST scan all Task, Bash, and Skill tool inputs for prompt injection patterns. MUST check critical patterns first (30 total), then high, then medium. First match determines severity.

REQ-GOV-032: Output Scanning

LLM threat detector MUST scan Write, Edit, Bash, NotebookEdit outputs for system prompt leakage (24 patterns) and sensitive data disclosure (using classification patterns). MUST emit LLM_THREAT events for all detections.

REQ-GOV-033: Severity Response

For critical/high severity threats, MUST block tool execution (input scan) or block output (output scan) and emit LLM_THREAT with outcome="block". For medium severity, MUST log warning with outcome="warn" and allow execution.

REQ-GOV-034: OWASP LLM Top 10 Coverage

Threat detector MUST address OWASP LLM01 (Prompt Injection), LLM06 (Sensitive Information Disclosure), and LLM09 (Overreliance) through pattern-based detection and output validation.

4.7 SIEM & Alerting

REQ-GOV-035: Alert Event Types

Alerting service MUST send alerts for: policy_deny, trust_deny, circuit_break, human_gate, llm_threat. All other events are audit-only.

REQ-GOV-036: Webhook Format

Webhook alerts MUST POST JSON with fields: source="governance", timestamp, event_type, agent_id, tool_name, outcome, detail (parsed from JSON), session_id, manifest_id, trust_level. Timeout MUST be 5 seconds.

REQ-GOV-037: Syslog Format

Syslog alerts MUST use RFC 5424 format with facility=local0 (16) and severity=3 (error) for deny/block, severity=4 (warning) for escalate/warn. MUST send via UDP.

REQ-GOV-038: Fail-Open

Alerting failures (network timeout, unreachable host) MUST NOT block governance operations. MUST silently continue after logging error.

4.8 Metrics & Monitoring

REQ-GOV-039: Metrics Database

Metrics collector MUST use separate SQLite database at state/governance-metrics.db with schema: timestamp, session_id, metric_type, agent_id, value (float), metadata (JSON).

REQ-GOV-040: Metric Types

MUST support metric types: agent_success, gate_trigger, delegation_depth, circuit_break, confidence_score. Additional types MAY be added without schema migration.

REQ-GOV-041: Session Summary

Metrics collector MUST provide session summary aggregation: count, average, and max value per metric_type for a given session_id.

4.9 Environment & Policy

REQ-GOV-042: Environment Detection

MUST detect environment from GOVERNANCE_ENV env var, falling back to hostname detection. MUST support: local, staging, production, c2. Default to "local" if unresolvable.

REQ-GOV-043: Centralized Policy

All governance components MUST reference state/governance-policy.yaml for: tool_tiers, classification_patterns, gate rules, tier_gate_matrix, retention policies. NO scattered config files.

REQ-GOV-044: Environment Overrides

MUST support environment-specific policy overrides at state/env-overrides/<env>.yaml. Overrides MUST deep-merge into base policy. Override values win on conflicts.

4.10 Hook Integration

REQ-GOV-045: SessionStart Hook

MUST load root agent manifest, generate session ID, initialize audit bus, emit MANIFEST_LOADED event, purge stale registry entries, apply retention policy archival.

REQ-GOV-046: PreToolUse Hook

MUST scan for prompt injection (threat detector), classify tool tier (policy engine), check manifest permissions, evaluate delegation (trust broker for Task tool), emit appropriate audit events.

REQ-GOV-047: PostToolUse Hook

MUST scan output for leakage (threat detector on Write/Edit/Bash/NotebookEdit), deregister completed tasks (trust broker), record metrics, emit LLM_THREAT events if detected.

REQ-GOV-048: Hook Timeout

All hooks MUST have timeout limits: SessionStart 10s, PreToolUse 10s, PostToolUse 10s. Timeout failures MUST fail-open (allow operation to proceed).

5. Complete Build Prompt

Copy this prompt and give it to Claude Code in a fresh project directory. It will generate the entire governance framework with all components, hooks, config files, and test fixtures.

I need you to build a complete Agent Governance & Trust Framework for Claude Code as a plugin.

## Architecture

Create a plugin at `governance/` with the following structure:

```
governance/
├── __init__.py
├── lib/
│   ├── __init__.py
│   ├── manifest.py           # Agent identity, signing, resolution
│   ├── trust_broker.py       # Delegation mediation, manifest registry
│   ├── policy_engine.py      # Tool classification, gate logic
│   ├── audit_bus.py          # SQLite event store with WAL
│   ├── memory_governor.py    # Content classification, provenance
│   ├── llm_threat_detector.py # OWASP LLM Top 10 patterns
│   ├── alerting.py           # Webhook + syslog
│   ├── metrics_collector.py  # Performance monitoring
│   ├── env_policy.py         # Environment detection
│   └── manifest_signing.py   # HMAC-SHA256 signing
├── hooks/
│   ├── hooks.json            # Hook registration
│   ├── session_start.py
│   ├── pre_tool_check.py
│   ├── approval_gate_hook.py
│   ├── post_task_cleanup.py
│   └── output_validator.py
├── state/
│   ├── governance-policy.yaml
│   ├── tool-tiers.yaml
│   ├── classification-patterns.yaml
│   ├── manifests/
│   │   ├── root.yaml
│   │   └── security-analyst.yaml
│   └── env-overrides/
│       └── production.yaml
└── tests/
    └── test_governance.py
```

## Core Components

### 1. Manifest System (lib/manifest.py)

Implement:
- Load static YAML manifests from state/manifests/
- HMAC-SHA256 signing with key at state/.signing-key
- SHA-256 content hash for tamper detection
- Parent ceiling enforcement: trust_level, data_classification, autonomy_depth
- Derive restrictive child manifests for unknown agents
- Validation against required fields

Required manifest fields:
- agent_id, manifest_id, manifest_version
- trust_level (1-5), data_classification (public/internal/confidential/restricted)
- permitted_tools (list of fnmatch patterns)
- permitted_delegations (list)
- human_required (bool)
- max_autonomy_depth (int), max_delegation_count (int)
- model_id, model_version

### 2. Trust Broker (lib/trust_broker.py)

Implement:
- Delegation validation: breadth limit (query audit bus for session count)
- Depth budget check (parent.depth - 1)
- Classification boundary (child cannot exceed parent)
- Trust escalation prevention
- Permitted delegation target check (fnmatch)
- Delegation token generation (SHA-256 hash)
- ManifestRegistry with file locking (fcntl), TTL purging (1 hour)

### 3. Policy Engine (lib/policy_engine.py)

Implement:
- Tool classification: exempt/standard/elevated from tool-tiers.yaml
- Unknown tools default to "elevated"
- Manifest permission check (fnmatch)
- Autonomy depth gate
- Human_required gate
- Conductor tier matrix: MAJOR + elevated = human_gate
- Sync audit for elevated/STANDARD+, async for others

### 4. Audit Bus (lib/audit_bus.py)

Implement:
- SQLite with WAL mode at state/audit.db
- 15 event types (EventType enum)
- Bounded queue (256 depth) with daemon worker
- Buffer fallback to state/audit-buffer.jsonl
- Buffer replay on SessionStart
- Schema with all required fields + indexes
- query() method with filterable columns
- export_jsonl() for session export
- purge_old_events() with archival to state/archive/
- Alerting callback integration
- Metrics callback integration

### 5. Memory Governor (lib/memory_governor.py)

Implement:
- Content classification via regex from classification-patterns.yaml
- Scan restricted first, then confidential, then internal
- Ceiling check: block if content classification exceeds agent ceiling
- Restricted = block (emit POLICY_DENY)
- Confidential = queue with pending_review tag (emit HUMAN_GATE)
- Public/internal = allow with provenance tags
- 9 provenance fields: gov_manifest_id, gov_agent_id, gov_manifest_version,
  gov_manifest_hash, gov_trust_level, gov_classification, gov_session_id,
  gov_task_id, gov_timestamp

### 6. LLM Threat Detector (lib/llm_threat_detector.py)

Implement:
- 30 prompt injection patterns (critical/high/medium)
- 24 system leakage patterns (critical/high/medium)
- Input scanning for Task, Bash, Skill tools
- Output scanning for Write, Edit, Bash, NotebookEdit
- Sensitive disclosure using classification patterns
- Emit LLM_THREAT events
- Block on critical/high, warn on medium

Patterns:
- Critical injection: delimiter injection, direct override, role hijacking
- High injection: indirect override, base64 encoding, instruction leakage
- Critical leakage: governance file paths, manifest internals, YAML structure
- High leakage: module references, session IDs

### 7. Alerting (lib/alerting.py)

Implement:
- Webhook POST (n8n compatible) with 5s timeout
- Syslog UDP RFC 5424 format (Wazuh compatible)
- Alert on: policy_deny, trust_deny, circuit_break, human_gate, llm_threat
- Fail-open design (never block on alerting failure)
- Config from governance-policy.yaml alerting section

### 8. Metrics Collector (lib/metrics_collector.py)

Implement:
- Separate SQLite at state/governance-metrics.db
- Schema: timestamp, session_id, metric_type, agent_id, value, metadata
- record() method (never raises)
- query_metrics() with filters
- get_session_summary() with count/avg/max per metric_type

### 9. Environment Policy (lib/env_policy.py)

Implement:
- detect_environment() from GOVERNANCE_ENV or hostname
- load_governance_policy() with deep-merge of env overrides
- Deep merge function (override wins on conflicts)

### 10. Manifest Signing (lib/manifest_signing.py)

Implement:
- generate_signing_key() → 32 bytes to state/.signing-key (0600 perms)
- load_signing_key() → bytes or None
- sign_manifest() → HMAC-SHA256 hex string
- verify_manifest_signature() → bool
- _canonicalize_manifest() → sorted JSON excluding volatile fields

## Hooks

### hooks.json

Register:
- SessionStart: session_start.py (timeout 10s)
- PreToolUse: approval_gate_hook.py, pre_tool_check.py (timeout 10s each)
- PostToolUse: post_task_cleanup.py (Task matcher), output_validator.py (Write|Edit|Bash matcher)

### session_start.py

1. Load root manifest (agent_id from env or default "root")
2. Generate session_id (gov-sess-{8 hex chars})
3. Initialize audit bus with alerting and metrics callbacks
4. Emit MANIFEST_LOADED event
5. Purge stale registry entries
6. Run retention policy archival if configured
7. Print session summary to stderr

### pre_tool_check.py

1. Load manifest from registry or resolve
2. If Task tool: trust_broker.evaluate_delegation()
3. LLM threat detector: scan_input()
4. Policy engine: evaluate()
5. If decision is deny: exit 1 with error message
6. If decision is human_gate: print gate prompt to stderr, wait for approval
7. If allow: exit 0

### approval_gate_hook.py

Check for external communication gate and data classification gate from
governance-policy.yaml gates section. Inject approval prompts per skill config.

### post_task_cleanup.py

For Task tool completion: deregister child manifest from registry.

### output_validator.py

1. Read tool output from stdin JSON
2. LLM threat detector: scan_output()
3. If critical/high threat detected: emit LLM_THREAT, exit 1
4. If medium: emit warning, exit 0
5. Record metrics

## Configuration Files

### state/governance-policy.yaml

Include sections:
- version, effective_from
- tool_tiers: exempt, standard, elevated, elevated_patterns
- classification_patterns: restricted, confidential, internal (regex lists)
- gates: external_communication, data_classification
- tier_gate_matrix: TRIVIAL/MINOR/STANDARD/MAJOR with gate modes
- retention: audit_events, metrics (retention_days, archive_path)
- environments: default, env_var
- alerting: enabled, webhook (url, enabled), syslog (host, port, facility, enabled)

### state/tool-tiers.yaml

List exempt, standard, elevated tools and elevated_patterns.

### state/classification-patterns.yaml

Regex patterns for restricted, confidential, internal classifications.

### state/manifests/root.yaml

Root agent with trust_level=5, data_classification=restricted, full permissions.

### state/manifests/security-analyst.yaml

Example agent with trust_level=4, confidential, limited tools and delegations.

## Tests

Write comprehensive pytest tests in tests/test_governance.py covering:
- Manifest loading, signing, ceiling enforcement
- Trust broker delegation validation (breadth, depth, classification)
- Policy engine tool classification and gate logic
- Audit bus emit, query, buffer fallback, retention
- Memory governor classification, ceiling, provenance
- LLM threat detector injection and leakage patterns
- Alerting webhook and syslog (mocked)
- Metrics recording and session summary
- Environment detection and policy merging

## Implementation Guidelines

- Use only stdlib (no external dependencies except PyYAML which is in Claude Code)
- All paths relative to plugin root via GOVERNANCE_PLUGIN_ROOT env var
- Never raise exceptions from audit, alerting, metrics (fail-open)
- Use WAL mode for all SQLite databases
- File locking (fcntl) for manifest registry
- Hooks read stdin JSON, write stderr for messages, exit 0/1 for allow/deny
- All timestamps in ISO 8601 UTC format
- All hashes in hexadecimal lowercase

Build the complete framework with all files. Make it production-ready.

6. Design Decisions

6.1 Fail-Open vs Fail-Closed

Decision: Hybrid Approach

Hook failures fail-open: If a hook times out or crashes, the tool execution proceeds. Rationale: Governance failures should not lock up the entire system. Users can still make progress while governance is degraded.

Trust/policy failures fail-closed: If trust broker or policy engine denies a delegation or tool, the operation is blocked. Rationale: Privilege escalation and unauthorized tool use are security-critical failures that must prevent execution.

Audit/alerting failures fail-open: If audit bus or alerting service fails, the operation continues. Events fall back to buffer. Rationale: Observability failures should not block functional operations.

6.2 SQLite vs External Database

Decision: SQLite with WAL Mode

Rationale: Governance framework must work on single-machine deployments without infrastructure dependencies. SQLite provides ACID guarantees, concurrent reads (via WAL), and zero operational overhead. For distributed deployments, audit events can be exported to external SIEM via webhook/syslog.

Trade-offs: SQLite limits to ~1M events before performance degradation. Retention policy archival mitigates this. Cannot query across multiple agent hosts without centralized aggregation. SIEM integration provides distributed visibility.

6.3 HMAC-SHA256 vs Ed25519

Decision: HMAC-SHA256

Rationale: HMAC-SHA256 is in Python stdlib (hashlib + hmac). Ed25519 requires PyNaCl or cryptography library, adding external dependencies. Manifest signing provides tamper evidence, not authenticity proof (shared secret vs asymmetric keys). HMAC is sufficient for this use case.

Trade-offs: HMAC cannot prove manifest authorship (anyone with the key can sign). Ed25519 would enable signature verification without access to signing key. For multi-party governance (untrusted manifest sources), Ed25519 would be preferred. For single-operator systems, HMAC is simpler.

6.4 Regex vs ML for Threat Detection

Decision: Regex Patterns

Rationale: Regex patterns are deterministic, auditable, and have zero inference latency. ML models (e.g., prompt injection classifiers) require GPU, model hosting, and introduce non-deterministic false positives. For governance hooks with 10s timeout, regex is the only viable approach.

Trade-offs: Regex patterns can be evaded (obfuscation, encoding, paraphrasing). ML models adapt to novel attacks. Future enhancement: add ML-based scanning as async post-analysis (emit events, train on patterns, update regex rules).

Pattern Maintenance: OWASP LLM Top 10 patterns require periodic updates. Governance policy YAML allows operators to add custom patterns without code changes.

6.5 Hook-Based vs Middleware Enforcement

Decision: Claude Code Plugin Hooks

Rationale: Hooks integrate natively with Claude Code's tool execution lifecycle. No need to wrap every tool or modify core runtime. Hooks receive full tool context (name, input, output) and can block or transform execution.

Trade-offs: Hooks run in separate processes (command-type hooks), adding 10-50ms overhead per tool invocation. In-process hooks (if Claude Code supported Python plugins) would be faster but less isolated. Current design prioritizes safety (hook crash doesn't crash agent) over performance.

6.6 Advisory vs Blocking Gates

Decision: Tier-Based Gate Matrix

Rationale: Not all governance violations warrant hard blocks. TRIVIAL tasks can skip most gates. MINOR tasks get advisory prompts. STANDARD tasks get blocking gates on critical operations. MAJOR tasks require human approval for all elevated tools.

Configurability: Tier-to-gate matrix in governance-policy.yaml allows operators to customize enforcement per task tier. Example: PRE_RELEASE gate is "skip" for TRIVIAL/MINOR, "advisory" for STANDARD, "blocking" for MAJOR.

Human-in-the-Loop: human_gate decision prints approval prompt to stderr and waits for operator input. Enables oversight without breaking agent autonomy.

6.7 Classification Ceiling vs Lattice Model

Decision: Linear Classification Order

Rationale: CLASSIFICATION_ORDER = ["public", "internal", "confidential", "restricted"] is a total order (linear hierarchy). Simpler to reason about and enforce than a lattice model (e.g., medical vs financial vs PII classifications that don't strictly order).

Trade-offs: Linear order doesn't capture orthogonal sensitivity dimensions. For complex data governance (HIPAA + PCI-DSS + GDPR), would need multi-dimensional classification with intersection logic. Current design optimizes for 80% use case (corporate data tiers).

6.8 Session-Scoped vs Global Registry

Decision: Session-Scoped Manifest Registry

Rationale: Each agent session gets isolated delegation tracking. session_id scoping prevents breadth limit circumvention via session restarts. TTL purging (1 hour) removes stale entries without manual cleanup.

Trade-offs: Session restart resets delegation count. Malicious agent could restart session to bypass breadth limit. Mitigation: SessionStart hook logs all manifest loads for forensic analysis. Future enhancement: persistent delegation ledger across sessions.

6.9 Provenance Tags vs Separate Index

Decision: Inline Provenance in Metadata

Rationale: Embedding 9 provenance fields in memory_store metadata (merged into Qdrant payload) keeps data + provenance together. No separate index to maintain or sync. Memory queries can filter by provenance (e.g., "gov_trust_level >= 4").

Trade-offs: Increases payload size by ~200 bytes per memory chunk. For 1M chunks, adds ~200MB storage. Alternative: separate provenance collection with foreign key links. Current design optimizes for query simplicity over storage efficiency.

6.10 Centralized vs Distributed Policy

Decision: Single governance-policy.yaml

Rationale: All governance components reference one file. Eliminates scattered config files, version skew, and partial updates. Git-tracked policy enables version control, diffs, and rollback. Environment overrides provide per-env customization without duplicating base policy.

Trade-offs: Single file becomes large (current: ~120 lines, projected: 500+ with all patterns). YAML parsing on every SessionStart adds ~10ms overhead. Alternative: compiled policy cache (pickle) with invalidation on YAML mtime change. Current design optimizes for simplicity.

7. Integration Points

7.1 Plugins System

Governance framework is a Claude Code plugin at ~/.claude/plugins/local/governance (symlink from project directory). Plugin manifest declares hooks:

{
  "description": "Governance enforcement hooks",
  "hooks": {
    "SessionStart": [{
      "hooks": [{
        "type": "command",
        "command": "python3 ${CLAUDE_PLUGIN_ROOT}/hooks/session_start.py",
        "timeout": 10
      }]
    }],
    "PreToolUse": [{
      "hooks": [{
        "type": "command",
        "command": "python3 ${CLAUDE_PLUGIN_ROOT}/hooks/pre_tool_check.py",
        "timeout": 10
      }]
    }],
    "PostToolUse": [{
      "matcher": { "tool_name": "Write|Edit|Bash|NotebookEdit" },
      "hooks": [{
        "type": "command",
        "command": "python3 ${CLAUDE_PLUGIN_ROOT}/hooks/output_validator.py",
        "timeout": 10
      }]
    }]
  }
}

Hooks receive tool context via stdin JSON and control execution via exit codes. Exit 0 = allow, exit 1 = deny. Stderr messages shown to user.

7.2 Agent System (Conductor)

Every agent receives a manifest at delegation time. Conductor plugin exports current task tier to conductor-state.json for policy engine consumption:

{
  "active_task": "task-a4f8d2c1",
  "agent_stack": ["root", "security-analyst"],
  "governance": {
    "conductor_tier": "STANDARD",
    "intent": {
      "sensitivity": "medium",
      "external_visibility": false
    }
  }
}

Trust broker reads this file during Task tool validation to determine if MAJOR + elevated tool requires human gate.

7.3 Memory System

Memory governor intercepts mcp__claude-memory__memory_store tool via PreToolUse hook. Provenance tags are merged into tool input before MCP tool execution:

# Original tool input
{
  "content": "Agent completed security analysis...",
  "collection": "claude_memories",
  "metadata": {}
}

# After memory governor
{
  "content": "Agent completed security analysis...",
  "collection": "claude_memories",
  "metadata": {
    "gov_manifest_id": "gov-sec-analyst-v2",
    "gov_agent_id": "security-analyst",
    "gov_trust_level": 4,
    "gov_classification": "confidential",
    "gov_session_id": "gov-sess-a4f8d2c1",
    "gov_timestamp": "2026-03-17T14:23:45.123456Z"
  }
}

Memory system (Qdrant) stores these tags in the payload. Queries can filter by provenance:

memory_recall("security analysis",
              filter={"gov_trust_level": {"$gte": 4}})

7.4 Context Management

Governance events (especially CONTEXT_PRESSURE, CIRCUIT_BREAK) inform context management decisions. When autonomy depth is exhausted, context manager can trigger human escalation or task decomposition instead of silent failure.

7.5 SIEM & Alerting

Audit bus sends events to external SIEM via webhook or syslog. Example n8n workflow:

# n8n webhook trigger receives governance events
# Filter: event_type in [policy_deny, trust_deny, llm_threat]
# Route to Slack/PagerDuty/Wazuh based on severity

Webhook → Filter → Switch (severity):
  - critical → PagerDuty incident
  - high → Slack security channel
  - medium → Wazuh log aggregation

7.6 Metrics & Observability

Metrics database enables trend analysis and anomaly detection. Example queries:

# Agent success rate over last 30 days
SELECT agent_id,
       AVG(value) as success_rate,
       COUNT(*) as invocations
FROM governance_metrics
WHERE metric_type = 'agent_success'
  AND timestamp > datetime('now', '-30 days')
GROUP BY agent_id
ORDER BY success_rate ASC;

# Gate trigger frequency by agent
SELECT agent_id,
       COUNT(*) as gate_count
FROM governance_metrics
WHERE metric_type = 'gate_trigger'
  AND timestamp > datetime('now', '-7 days')
GROUP BY agent_id
ORDER BY gate_count DESC;

7.7 Development Workflow

Governance framework development uses standard Python tooling:

# Install in development mode
cd ~/.claude/plugins/local/governance
pip install -e .

# Run tests
pytest tests/ -v

# Lint
ruff check governance/

# Type check
mypy governance/lib/

# Generate signing key
python3 -c "from governance.lib.manifest_signing import generate_signing_key; \
            generate_signing_key()"

# Export session audit trail
python3 -c "from governance.lib.audit_bus import AuditBus; \
            from pathlib import Path; \
            bus = AuditBus(Path('state/audit.db'), Path('state/audit-buffer.jsonl')); \
            bus.export_jsonl('gov-sess-a4f8d2c1', Path('audit-export.jsonl'))"

Production Deployment Checklist
Before deploying governance framework to production:

Generate unique signing key per environment (do NOT share keys)
Configure SIEM webhook URL and verify connectivity
Set retention policies based on compliance requirements (90/365/730 days)
Create production manifest for each agent with least-privilege permissions
Test all governance gates in staging with realistic workloads
Set up alerting channels (Slack, PagerDuty, email)
Document human approval workflows for confidential/restricted gates
Schedule periodic manifest audits (quarterly review of trust levels)
